| Frame Material | Cast Iron Cast Iron | |
| Impregnation Method | Constant Resin Flow Constant Resin Flow | |
| Regreasing System | At Drive end and Non-drive end At Drive end and Non-drive end | |
| Main terminal box hole | 2xM63x1,5 2xM63x1,5 | |
| Shaft Locking Device | Without Without | |
| Shaft Material | SAE 1040/45 Carbon Steel SAE 1040/45 Carbon Steel | |
| Painting | RAL 5009 203A (ISO 12944 - C3) RAL 5009 203A (ISO 12944 - C3) | |
| Grounding Lugs | Double Double | |
| Fan Cover material | Cast Iron Cast Iron | |
| Tropicalized Painting | Without Without | |
| Frame | 315S/M 315S/M | |
| Winding thermal protection | Thermistor - 2 wires 1 per phase 155°C Thermistor - 2 wires 1 per phase 155°C | |
| Output | 90 kW (125 HP) 90 kW (125 HP) | |
| Drip Cover | Without Without | |
| Frequency | 50 Hz 60 Hz | |
| Rated speed | 993 rpm 1194 rpm | |
| Slip | 0.70 % 0.50 % | |
| Rated voltage | 400/690 V 460 V | |
| Rated current | 172/100 A 151 A | |
| L. R. Amperes | 1238/718 A 1179 A | |
| LRC | 7.2 7.8 | |
| Overload protector (phenolic) | Without overload protector Without overload protector | |
| Connection Cables Quantity | 6 6 | |
| No load current | 86.0/49.9 A 78.0 A | |
| Fan material | Plastic Plastic | |
| Rated torque | 88.3 kgfm 73.4 kgfm | |
| Screw cap | STAINLESS STEEL AISI 316L STAINLESS STEEL AISI 316L | |
| Locked rotor torque | 250 % 280 % | |
| NDE bearing Seal | WSeal WSeal | |
| Breakdown torque | 290 % 320 % | |
| DE bearing Seal | WSeal WSeal | |
| Locked rotor time | 43s (cold) 24s (hot) 54s (cold) 30s (hot) | |
| Moment of inertia (J) | 7.96 kgm² 7.96 kgm² | |
| Design | NE NE | |
| Insulation Class | F F | |
| Service factor | 1.00 1.00 | |
| Duty Cycle | S1 S1 | |
| Starting Method | Direct On Line Direct On Line | |
| Ambient temperature | -20°C to +40°C -20°C to +40°C | |
| Altitude | 1000 m.a.s.l. 1000 m.a.s.l. | |
| Degree of Protection | IP55 IP55 | |
| Enclosure | IC411 - TEFC IC411 - TEFC | |
| Mounting | B3T B3T | |
| Rotation¹ | Both (CW and CCW) Both (CW and CCW) | |
| Noise level² | 67.0 dB(A) 70.0 dB(A) | |
| Approx. weight³ | 997 kg 997 kg | |
| Flange | Without Without | |
| Efficiency (100% load) | 95.6 95.8 | |
| Power factor (100% load) | 0.79 0.78 | |
| Bearing type | 6319 C3 6319 C3 | |
| NDE bearing | 6316 C3 6316 C3 |
